X-CUBE X2 COMPACT

SMART. EFFICIENT. COMPACT.

SMART AND INTELLIGENT DESIGN

  • Selection, installation and intuitive control system with wireless communication

  • Most hygienic design in the market, Eurovent certified with filter class up to F9

  • Fully prewired controls and prepared for BMS integration with BACNet or Modbus


ENERGY EFFICIENT PERFORMANCE

  • High efficiency free-running EC Fans
  • Heat Recovery - efficiency up to 82%
  • Leakage class L1
  • Thermal transmittance class T2
  • Thermal bridging class T2
  • Ultra Efficient Run Around Coil Technology

COMPACT SIZE AND LOWER LIFE CYCLE COST

  • Robust and durable for longer life, with class C4 corrosion resistance
  • Minimum space required with efficient performance
  • Integrated systems technology for efficient operation

YOU HAVE THE CHOICE

HORIZONTAL CONNECTION

with rotary heat exchanger

VERTICAL CONNECTION

with rotary heat exchanger

HORIZONTAL CONNECTION

with plate heat exchanger



X-CUBE X2 COMPACT COMPARISONS

TROX offers the most intuitive, energy-efficient and lowest life cycle costs for Compact Air Handling Units for any project.


Horizontal with Rotary Heat Exchanger
Vertical with Rotary Heat Exchanger
Horizontal with Plate Heat Exchanger
Number of Variants
9 sizes
4 sizes
6 sizes
Airflow m3/h
1,400 - 15,000
1,700 - 5,600
1,800 - 10,400
Installation Type
Indoor and Outdoor
Indoor
Indoor and Outdoor
Corrosion Resistance
Heating
Integrated Heating Coil
Heat Recovery System with counterflow heat exchanger



X-CUBE X2 COMPACT - THE SMART AIR HANDLING UNIT

SMART, EFFICIENT. COMPACT.

The ready-to-connect and pre-configured X-CUBE X2 compact air handling unit has continued the excellent features of type X-CUBE X2. The X2 compact is individually configurable and is optimised to suit local climate requirements.


conveniently COMPACT size. immediately ready to use.

Due to the small size and the variable versions with vertical or horizontal duct connection, installation is possible in the smallest of spaces. The slim units fit largely through standard doors and are easy to transport.

The units are supplied ready for connection and can be configured and commissioned via X-CUBE control in a very short time.

X-CUBE CONFIGURATOR

FIND THE RIGHT UNIT – FAST

  • Simple online design and sizing of X-CUBE air handling units

  • Configuration possible without expert knowledge

  • Secure 24/7 access via myTROX portal

  • LCC tool to determine the expected operating costs

  • *Output of CO2 emissions with a known energy mix possible


► Configure your X-CUBE X2 compact here! ►►

WHY CHOOSE X-CUBE COMPACT?

smart control.

Easy to use control system with status display of all functions and integrated alarm messages such as for filter replacement.

hygienic design.

The most hygienically designed AHU in the market, with smooth surfaces, no protruding frame parts and world-class filtration.

ENERGY EFFICIENT.

Run around coil technology, high efficiency EC Fans and heat recovery efficiency up to 82%, achieves leakage class L1.

EASy to use.

A plug and play Air Handling Unit with factory pre-configured smart integrated controls for easy installation and operation.

COMPACT SIZE.

Fits through standard doorways for easier access and flexibility in installation and maintenance, and a lower life cycle cost.

FAST DELIVERY.

Selected variants are available from stock, with units ready to be dispatched within 14 days from confirmed order.

EXPLORE SOME SUCCESSFUL TROX PROJECTS!

QUADRAM INSTITUTE, NORWICH

A dedicated laboratory air management system, supplied by TROX, has been installed to optimise safety and environmental performance in a major new clinical and research facility. The TROX EASYLAB system, incorporating TROX VAV controllers, specialist filters, grilles and diffusers, will assist Norfolk-based Quadram Institute to meet the stringent requirements for its world-class research.

The new Quadram Institute building, based at the Norwich Research Park, brings together the former Institute of Food Research, the University of East Anglia Clinical Research Facility and the gastrointestinal endoscopy unit of Norfolk and Norwich University Hospital to conduct ground-breaking translational research and clinical care around four research themes: Food Innovation and Health; Gut Microbiology; Microbes in the Food Chain; and Population Health. The new facility will house 300 researchers, as well as clinicians and support staff. In addition, as the largest unit of its type in Europe, it will welcome up to 40,000 endoscopy outpatients each year. The building provides distinct accommodation for each department, as well as shared office space, meeting rooms and amenities to encourage interaction between all user groups.


► Click here for the project report! ►►

TROX UK MSCB UBS Exterior Image

Exterior of UBS

5 BROADGATE, LONDON

This innovative "groundscraper" designed by Ken Shuttleworth of Make Architects provides a new headquarters for UBS allowing the organisation to consolidate its London trading operations into one building.  The new building, which forms part of the Broadgate Estate,  will house up to 6,000 people and features four immense trading floors in 700,000 sq ft of Grade "A" office space.

5, Broadgate is described as one of the most sustainable office buildings of all time.  Make Architects highlight that the sustainable features of the building include "the second biggest array of photovoltaic cells and solar thermal panels in the City of London, a substantial area of green roof, 70 percent waste recycling, FSC-certified timber, and a BREEAM Excellent rating".


► Click here for the project report! ►►

FURTHER REFERENCE PROJECTS

TROX technology developed in the UK and Germany stands for the highest quality and efficiency. In-house research and development, manufacturing and test laboratories ensure maximum processing quality and functional reliability. This is complemented by a wide range of services including the 24/7 myTROX digital customer portal with comprehensive product information and databases.

Discover more impressive reference projects and learn more about our successful cooperation across a diverse portfolio of applications and industry sectors.

Take a look at our projects now and let our expertise convince you.


► Discover more reference projects! ►►



ANY QUESTIONS?

WE WILL GLADLY ADVISE YOU.

Describe your specific needs to us or arrange a non-binding consultation.

Contact your TROX Specification Sales Team

Mr Alan Cansell (Business Development Director) and Mr Steve Law (Sales Director)

E-Mail: consult@troxuk.co.uk

Phone: +44 (0)1842 754545
